Lenovo

Legion Go 8APU1(Withdrawn)

Legion Go 8APU1(Withdrawn)

83E1004YAX

695.000 JOD
695.000 JOD
ŲŖŲ®ŁŁŠŲ¶ Ų§Ł„Ų³Ų¹Ų± Ł†ŁŲ°
Ų“Ų­Ł† Ł…Ų­Ų³ŁˆŲØŲ© Ų¹Ł†ŲÆ Ų§Ł„Ų®Ų±ŁˆŲ¬.
rocessor Family
AMD Ryzenā„¢ Z Series Processor
Processor**
Processor Name Cores Threads Base Frequency Max Frequency Cache Memory Support Processor Graphics
AMD Ryzenā„¢ Z1 6 12 3.2GHz 4.9GHz 6MB L2 / 16MB L3 LPDDR5X-7500 AMD Radeonā„¢ Graphics
AMD Ryzenā„¢ Z1 Extreme 8 16 3.3GHz 5.1GHz 8MB L2 / 16MB L3 LPDDR5X-7500 AMD Radeonā„¢ Graphics
Operating System
Operating System**
  • WindowsĀ® 11 Home
  • WindowsĀ® 11 Home Single Language
Graphics
Graphics
Graphics Type Memory Key Features
AMD Radeonā„¢ Graphics Integrated Shared DirectXĀ® 12
Chipset
Chipset
AMD SoC (System on Chip) platform
Memory
Max Memory
16GB soldered memory, not upgradable
Memory Slots
Memory soldered to systemboard, no slots
Memory Type
LPDDR5X-7500
Storage
Max Storage Support[1]
One drive, up to 1TB M.2 2242 SSD
Storage Slot[2]
One M.2 2242 PCIeĀ® 4.0 x4 slot
Storage Type
Disk Type Interface Offering
M.2 2242 SSD PCIeĀ® NVMeĀ®, PCIeĀ® 4.0 x4 256GB / 512GB / 1TB
Notes:
1. The storage capacity supported is based on the test results with current LenovoĀ® storage offerings.
2. The actual data transfer rate of the following PCIeĀ® interface also depends on the capabilities of the connected PCIeĀ® device. The listed values represent theoretical maximums. PCIeĀ® 3.0 (x2 / x4): 2 GB/s (16 Gbps) / 4 GB/s (32 Gbps); PCIeĀ® 4.0 (x2 / x4): 4 GB/s (32 Gbps) / 8 GB/s (64 Gbps); PCIeĀ® 5.0 (x2 / x4): 8 GB/s (64 Gbps) / 16 GB/s (128 Gbps).
Removable Storage
Card Reader
microSD card reader
Multi-Media
Audio Chip
High Definition (HD) Audio
Speakers
Stereo speakers, 2W x2
Microphone
Dual-microphone array
Camera
No camera
Sensor
Sensors
  • Accelerometer + 6-axis Gyroscope sensor
  • Ambient light sensor (ALS)
  • Mouse sensor
Battery
Battery
49.2Wh Rechargeable Li-ion Battery, supports Super Rapid Charge (10min charge 0~30% capacity, 30min charge 0~70% capacity, 80min charge 0~100% capacity)
Max Battery Life[1]
  • Controllers: 11 hr
  • Gamepad with controllers: MobileMarkĀ® 25: 7.1 hr Local video (1080p) playback@150nits: 7.55 hr
Notes:
1. All battery life claims are approximate maximum and based on results using the MobileMarkĀ® 2014, MobileMarkĀ® 2018, MobileMarkĀ® 25, MobileMarkĀ® 30, JEITA 2.0, JEITA 3.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter**[1]
  • 65W USB-CĀ® (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
  • 65W USB-CĀ® slim (wall-mount) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
Notes:
1. AC adapter offerings depend on the country.
Special Features
Special Features
Legion Coldfront cooling system
Design
Display
Display[1]
Size Resolution Touch Type Brightness Surface Aspect Ratio Contrast Ratio Color Gamut Refresh Rate Viewing Angle (L/R/U/D) Key Features
8.8" WQXGA (2560x1600) Multi-touch IPS 500nits Glossy, anti-fingerprint 16:10 1500:1 97% DCI-P3 144Hz 89Ā° / 89Ā° / 80Ā° / 80Ā° CorningĀ® GorillaĀ® Glass 5
Touchscreen
In-cell multi-touch, supports 10-point touch
Notes:
1. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Multi-mode
Multi-mode
Handheld mode: Play with controllers attached to enjoy the 8.8" gamepad Detachable mode: Flip the stand to share the gamepad, then share the fun with a multiplayer game FPS mode: Flip the stand, turn on FPS mode and put the right controller on the dock TV mode: Dock your system to enjoy games on TV (via USB4Ā® port)
Input Device
Pen
No support
Touchpad
Buttonless MylarĀ® surface touchpad (on the right controller), 28.5 x 28.5 mm (1.12 x 1.12 inches)
Controls
A B X Y buttons D-pad Touchpad FPS mode switch Mouse wheel Left & right Joysticks Left & right release buttons LB button M1 / RB button M2 button Y1 & Y2 buttons M3 & Y3 buttons 4x function buttons
Mechanical
Dimensions (WxDxH)[1]Ā Click here to see dimension diagram
Models Dimensions
Gamepad 210 x 131 x 20.1 mm (8.27 x 5.16 x 0.79 inches)
Gamepad with controllers 298.83 x 131 x 40.7 mm (11.76 x 5.16 x 1.60 inches)
Carry bag 332 x 162 x 83 mm (13.07 x 6.38 x 3.27 inches)
Weight[2]
Models Weight
Gamepad Less than 640 g (1.41 lbs)
Gamepad with controllers Less than 854 g (1.88 lbs)
Case Color
Shadow black
Case Material
PC + GF (gamepad), PC-ABS (controllers)
Surface Treatment
Painting (gamepad), laser special texture (controllers)
Others
  • Power button
  • Volume keys
Notes:
1. The system dimensions may vary depending on configurations.
2. The system weight is approximate and based on results in LenovoĀ® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
Connectivity
Network
WLAN + Bluetooth[1]
AMD Wi-FiĀ® 6E RZ616, 802.11ax 2x2 Wi-FiĀ® + BluetoothĀ® 5.3
WWAN
No support
Ethernet
No onboard Ethernet
Notes:
1. Wi-FiĀ® operation (including Wi-FiĀ® 6, Wi-FiĀ® 6E, Wi-FiĀ® 7, etc.) is subject to the regulatory requirements of each country. BluetoothĀ® may operate at a lower version than hardware design depending on the factors such as operating system, driver, etc.
Ports[1]Click here to see ports position
Standard Ports
  • 2x USB4Ā® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPortā„¢ 1.4)
  • 1x Headphone / microphone combo jack (3.5mm)
  • 1x Card reader
  • 2x Pogo pin connector (5-point)
Notes:
1. The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB4Ā® 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; USB4Ā® 40Gbps (USB 40Gbps): 40 Gbit/s; Thunderboltā„¢ 3/4: 40 Gbit/s. Thunderboltā„¢ 5: 80 Gbit/s (bidirectional), up to 120 Gbit/s in bandwidth boost mode for video-intensive applications.
Security & Privacy
Security
Security Chip
Firmware TPM 2.0 integrated in SoC
Fingerprint Reader
No fingerprint reader
BIOS Security
  • Administrator password
  • Master hard disk password
  • Power-on password
  • User hard disk password
  • User password
  • Self-healing BIOS
  • More BIOS security features, please visit BIOS Simulator[1]
Notes:
1. The BIOS simulator is just for reference. Default settings and some options may vary depending on the hardware, operating system and BIOS version.
Service
Warranty
Base Warranty**
  • 1-year courier or carry-in service
  • 1-year courier or carry-in with 2-year system board service (Korea only)
  • 2-year (1-yr battery) courier or carry-in service
  • 3-year (1-yr battery) courier or carry-in service
